HC-80T Three Guide Column High Speed Power Press

Short Description:

1.Manufactured from high tensile cast iron, stress relieved for maximum rigidity and long termaccuracy. It’s the best for continuous production.
2.Double pillars and one plunger guide structure, manufactured from copper bush instead of traditional board for minimize friction. Work with forced lubrication to minimize thermal strainlife of the frame, upgrade stamping quality and extend service life of the machine.

Send email to us

Product Detail

Product Tags

Main Technical Parameters:

Model		HC-80T
Capacity	KN	800
Stroke length	MM	30 40	50
Maximum SPM	SPM	500 400	350
Minimum SPM	SPM	200 200	200
Die height	MM	250-300 245-295	240-290
Die height adjustment	MM	50
Slider area	MM	680×450
Bolster area	MM	1000×650×130
Bolster opening	MM	150×820
Main motor	KW	18.5kw×4P
Accuracy		JIS/JIS Special	grade

Main Features:

1.Manufactured from high tensile cast iron, stress relieved for maximum rigidity and long termaccuracy. It's the best for continuous production.
2.Double pillars and one plunger guide structure, manufactured from copper bush instead of traditional board for minimize friction. Work with forced lubrication to minimize thermal strainlife of the frame, upgrade stamping quality and extend service life of the machine.
3.Balancer device for optional to reduce vibration, make press more precision and stable.
4.It's more convenient to adjust the die with the die height indicator and the hydraulic locking device.
5.HMI is controlled by microcomputer. Display value and fault monitoring system. It is easy to operate.
6.Adopt die height adjustment motor, with die height indicator, easy to adjust the die height.
