HC-65TW Three Guide Column High Speed Power Press

C-Type High Speed Precision Press

HC-65TW Three Guide Column High Speed Power Press

  • Model HC-65TW
  • Capacity 650 KN
  • Die height adjustment 50 MM
  • Slider area 600x400 MM
  • Bolster area 890x580x130 MM
  • Bolster opening 150x740 MM

1. Manufactured from high tensile cast iron, stress relieved for maximum rigidity and long termaccuracy. It's the best for continuous production.

2. Double pillars and one plunger guide structure, manufactured from copper bush instead of traditional board for minimize friction. Work with forced lubrication to minimize thermal strainlife of the frame, upgrade stamping quality and extend service life of the machine.

Model HC-65TW
Capacity KN 650
Stroke length MM 30 40 50
Maximum SPM SPM 600 550 500
Minimum SPM SPM 200 200 200
Die height MM 215-265 210-260 205-255
Die height adjustment MM 50
Slider area MM 600×400
Bolster area MM 890×580×130
Bolster opening MM 150×740
Main motor KW 11kw×4P
Accuracy JIS/JIS Special grade

Dimension
PRODUCT DETAIL

HC-65TW Three Guide Column High Speed Power Press

Main Features
PRODUCT DETAIL

  • Balancer device for optional to reduce vibration, make press more precision and stable.

  • It's more convenient to adjust the die with the die height indicator and the hydraulic locking device.

  • HMI is controlled by microcomputer. Display value and fault monitoring system. It is easy to operate.

  • Adopt die height adjustment motor, with die height indicator, easy to adjust the die height.

Main Components
PRODUCT DETAIL

motor
01

Main Motor

workbench
01

bolster

control button
01

Control buttons

slider
01

slider

Punch angle display
01

Die Height Indicator

flywheel
01

flywheel

feeder
01

feeder

Control panel
01

Human-Machine Interface

Locking pump
01

Locking pump

Press Products
PRODUCT DETAIL

HC-80T Three Guide Column High Speed Power Press  (1)
01
HC-80T Three Guide Column High Speed Power Press  (2)
01
HC-80T Three Guide Column High Speed Power Press  (3)
01

Product fAQPRODUCT DETAIL

  • Question: Is Howfit A Press Machine Manufacturer Or A Machine Trader?

  • Question: Is It Convenient To Visit Your Company?

  •  Question: How Many Countries Had You Been Successfully Made A Deal With?

  •  Question: What Is The Tonnage Range Of Howfit High Speed Press?

Auxiliary Equipment
PRODUCT DETAIL

Feeder
01

Electrical cabinet

Continuously delivers metal coil in precise steps to the press or processing equipment during stamping operations

Decoiler
01

Decoiler

Used for uncoiling and recoiling sheet metal from coils, ensuring a smooth and steady material feed

Straightener
01

Straightener

Flattens uneven sheet or strip material by passing it through upper and lower rollers to achieve the required flatness

Scrap chopper
01

Scrap chopper

Collects and removes scrap generated during the stamping process to maintain clean and efficient operation
